How to Make a Pattern for a “Simmons-Skinner” Blend

In this post I explain how to make a pattern for a blend between two colors of clay to produce a desired color gradient.

When Judith Skinner introduced her revolutionary blend technique, she started with two triangles of different colors lined up along their hypoteneuses to form a rectangle. As I explained in a 2011 post, the straight line between the colors should be a curve if the goal is to create an even color gradient. That is:

compare straight with curved short

This post explains how you can determine the shape of that curve. Before I do that, though, I should remind you how to mix simple color scales (a concept Maggie Maggie introduced to the polymer world.)

Diagram of Color Scales in Progress.

This image shows color scales between zinc yellow and ultramarine in progress. Look first at the bottom row. It shows how the clay was measured out before mixing. On the far left is the 1/2 and 1/2 mixture of the two colors. Moving from left to right along the bottom, each square contains half as much yellow as the one before it.  In the top row the yellow increases toward the right. This type of sequence in which an amount is halved (or doubled) in each step is called a geometric progression. This 2011 post explains the process in more detail. A second approach is described in Polymer Clay Color Inspirations, a book by Maggie Maggio and Lindly Haunani.

Before you can create your pattern you must mix the geometric progression for the two colors you are using. After mixing the clay roll into into thin sheets and punch 2 small circles in each mixture. Leave everything on your work surface, labeled, until you are ready to use it.

Color mixtures from cobalt to zinc on labeled sheet of glass.

Color mixtures from cobalt to zinc on labeled sheet of glass.

You are going to place one set of dots along the bottom of a sheet of graph paper that looks like this.

"Log-Normal" Graph Paper for Blend Patterns

“Log-Normal” Graph Paper for Blend Patterns

This paper looks complicated, but it’s not. You can make it yourself:

  1. Draw a rectangle the width of your pasta machine and as tall as you want your sheet of clay to be.
  2. Draw a vertical line down the center. Write 1/2  just above it.
  3. Draw several equally spaced lines to the left and the right of the center line.
  4. Measure halfway up from the bottom line of the rectangle and draw a horizontal line all the way across. Label it 1/2 at both ends.
  5. Measure 1/4 of the way up and draw a horizontal line all the way across. Label it 1/4 at both ends.
  6. Measure 3/4 of the way up and draw a horizontal line all the way across. Label it 3/4 at both ends.
  7. Do the same for each of these proportions: 1/128, 1/64, 1/32, 1/16, 15/16, 31/32, 63/64, 127/128.  The graph should look like the picture above.

Place the graph inside a sheet protector so the clay dots will stick to the surface. Arrange the dots along the bottom line of the graph, spreading them out the way you want the hues spread out in the final blend. Ignore the vertical lines while you do this. (Note: the fractions on the bottom will not be on the graph – they are put here to indicate the proportions of the two colors in the mixtures.)

Graph with dots spread across bottom.

Graph with dots spread across bottom. (Labels are not necessary.)

Now you are ready to put the second set of dots on the graph to form the curve. The general idea is to put each new dot directly above its identical partner. The distance above is determined by the proportions of the 2 colors in the dot.  For example, the 1/2 blue and 1/2 yellow dot goes right on top of the hoizontal line labeled 1/2.

four dots on curve

Notice that the dot is more than half way across the graph even though it is half yellow and blue. That is because the mixture is blue-green and I want the center of the blend to be green. The 3/4 mixture is closer to true green. Repeat this step with all of the other dots. When you are finished your graph should look like the bottom left. paired graph and pattern2

To make the pattern, mark the locations of the centers of the dots on a new sheet of graph paper. Connect the dots, draw a rectangle around the outside and your pattern is finished. Notice that the curved line does not go all the way to the corner on either side. This ensures that you will have a narrow strip of the original colors at the beginning and end of the blend. Label the pattern with the colors you used as shown above.  This is important because the pattern for each color combination will be different.
